EVIRONMENTAL RATING
-----------------(MAXIMUM)---------------

Operating Temperature ...................-65°C to +150°C
Storage Temperature.......................-65°C to +200°C.

Chip Limiter Diodes

Chip and Packaged Limiter Diodes

Heatsink is Cathode

Part Number Case Style
Vbr(min)
Cj(max) @ 10V
Rs(typ)
TL(typ)
Application
Ir= 10mA
f= 1 MHz
If= 10mA
If= 10/6mA
(volts)
(pF)
( W )
(nS)
PIN Diode
MP5021
15
0.12
2
10
Limiter Diode
PIN Diode
MP5022
15
0.12
2
10
Limiter Diode
PIN Diode
MP5023
15
0.12
2
10
Limiter Diode
PIN Diode
MP5024
15
0.12
2
10
Limiter Diode
PIN Diode
MP5025
15
0.12
2
10
Limiter Diode
PIN Diode
MP5026
15
0.15
2
10
Limiter Diode
PIN Diode
MP5027
15
0.15
2
10
Limiter Diode
PIN Diode
MP5028
15
0.15
2
10
Limiter Diode
PIN Diode
MP5029
15
0.15
2
10
Limiter Diode
PIN Diode
MP5030
15
0.15
2
10
Limiter Diode
PIN Diode
MP5032
30
0.08
2
20
Limiter Diode
PIN Diode
MP5031
30
0.08
2
20
Limiter Diode
PIN Diode
MP5033
30
0.08
2
20
Limiter Diode
PIN Diode
MP5034
30
0.08
2
20
Limiter Diode
PIN Diode
MP5035
30
0.08
2
20
Limiter Diode
PIN Diode
MP5036
30
0.12
2
20
Limiter Diode
PIN Diode
MP5037
30
0.12
2
20
Limiter Diode
PIN Diode
MP5038
30
0.12
2
20
Limiter Diode
PIN Diode
MP5039
30
0.12
2
20
Limiter Diode
PIN Diode
MP5040
30
0.12
2.0
20
Limiter Diode
PIN Diode
MP5041
70
0.12
1.5
35
Limiter Diode
PIN Diode
MP5042
70
0.12
1.5
35
Limiter Diode
PIN Diode
MP5043
70
0.12
1.5
35
Limiter Diode
PIN Diode
MP5044
70
0.12
1.5
35
Limiter Diode
PIN Diode
MP5045
70
0.12
1.5
35
Limiter Diode
PIN Diode
MP5046
70
0.15
1.5
35
Limiter Diode
PIN Diode
MP5047
70
0.15
1.5
35
Limiter Diode
PIN Diode
MP5048
70
0.15
1.5
35
Limiter Diode
PIN Diode
MP5049
70
0.15
1.5
35
Limiter Diode
PIN Diode
MP5050
70
0.15
1.5
35
Limiter Diode
PIN Diode
MP5081
100
0.08
2
50
Limiter Diode
PIN Diode
MP5082
100
0.08
2
50
Limiter Diode
PIN Diode
MP5083
100
0.08
2
50
Limiter Diode
PIN Diode
MP5084
100
0.08
2
50
Limiter Diode
PIN Diode
MP5085
100
0.08
2
50
Limiter Diode
PIN Diode
MP5086
100
0.15
2
50
Limiter Diode
PIN Diode
MP5087
100
0.12
2
50
Limiter Diode
PIN Diode
MP5088
100
0.12
2
50
Limiter Diode
PIN Diode
MP5089
100
0.12
2
50
Limiter Diode
PIN Diode
MP5090
100
0.12
2
50
Limiter Diode

Part Number
Typical Performance
Peak Pin (1.0 mS)
(dBm)

Threshold
(dBm)

Leakage POUT
(dBm)

Insertion Loss
(dBm)
CW Power in
(W)
TL
(ns)

q jc
(
C/W)

MAX.
Typ.
Typ.
Typ.
MAX.
Typ.
Typ.
MP5021
+47
+7
+21
0.10
2
5
100
MP5022
+47
+7
+21
0.10
2
5
100
MP5023
+47
+7
+21
0.10
2
5
100
MP5024
+47
+7
+21
0.10
2
5
100
MP5025
+47
+7
+21
0.10
2
5
100
MP5026
+50
+7
+24
0.10
3
5
80
MP5027
+50
+7
+24
0.10
3
5
80
MP5028
+50
+7
+24
0.10
3
5
80
MP5029
+50
+7
+24
0.10
3
5
80
MP5030
+50
+7
+24
0.10
3
5
80
MP5031
+47
+12
+24
0.10
3
10
80
MP5032
+47
+12
+24
0.10
3
10
80
MP5033
+47
+12
+24
0.10
3
10
80
MP5034
+47
+12
+24
0.10
3
10
80
MP5035
+47
+12
+24
0.10
3
10
80
MP5036
+50
+12
+27
0.10
4
10
60
MP5037
+50
+12
+27
0.10
4
10
60
MP5038
+50
+12
+27
0.10
4
10
60
MP5039
+50
+12
+27
0.10
4
10
60
MP5040
+50
+12
+27
0.10
4
10
60
MP5041
+53
+15
+27
0.10
3
20
40
MP5042
+53
+15
+27
0.10
3
20
40
MP5043
+53
+15
+27
0.10
3
20
40
MP5044
+53
+15
+27
0.10
3
20
40
MP5045
+53
+15
+27
0.10
3
20
40
MP5046
+56
+15
+29
0.15
4
20
20
MP5047
+56
+15
+29
0.15
4
20
20
MP5048
+56
+15
+29
0.15
4
20
20
MP5049
+56
+15
+29
0.15
4
20
20
MP5050
+56
+15
+29
0.15
4
20
20
MP5081
+60
+20
+39
0.15
6
50
20
MP5082
+60
+20
+39
0.15
6
50
20
MP5083
+60
+20
+39
0.15
6
50
20
MP5084
+60
+20
+39
0.15
6
50
20
MP5085
+60
+20
+39
0.15
6
50
20
MP5086
+63
+20
+41
0.15
10
50
10
MP5087
+63
+20
+41
0.15
10
50
10
MP5088
+63
+20
+41
0.15
10
50
10
MP5089
+63
+20
+41
0.15
10
50
10
MP5090
+63
+20
+41
0.15
10
50
10
